Description
In the world of industrial applications, ensuring that panel holes and access points are effectively sealed is crucial for maintaining both safety and functionality. Professional Blanking Plugs offer an ideal solution for these needs, combining durability with ease of use. Here's a comprehensive look at these essential components.
Key Features
Manufactured From Nylon 6/6:
These blanking plugs are made from high-quality Nylon 6/6, known for its excellent mechanical properties. This material ensures strength, resilience, and resistance to impact, making it suitable for demanding industrial environments.
Available in Black or White Finish:
The plugs come in two versatile colors, black and white, allowing them to blend seamlessly with a variety of panel finishes. This aesthetic flexibility ensures that they can be used in different applications without compromising the visual appeal of the installation.
Built-In Locking Fingers:
Equipped with locking fingers, these plugs provide a secure fit, preventing them from dislodging or falling out. This feature is especially important in high-vibration environments where stability and reliability are paramount.
Thin Domed Head:
The design includes a thin domed head that not only contributes to a sleek appearance but also allows for easy removal and insertion. This design element is particularly useful in applications where frequent access to the panel is required.
Commonly Used For
Blanking Off or Finishing Excess Panel Holes: One of the primary applications of these plugs is to cover and seal off unused or excess holes in panels. This prevents dust, dirt, and other contaminants from entering sensitive areas, thus maintaining the integrity and cleanliness of the equipment.
Cable Threading Ports for Access Holes:
They can also serve as cable threading ports, providing a clean and professional finish to access holes used for cable routing. This helps in organizing and protecting cables, enhancing both safety and aesthetics.
Usage:
Ideal for industrial panels, these plugs are used to seal off unnecessary holes and manage cable access, enhancing both functionality and safety in industrial settings.
Specifications
To Fit Hole Diameter
Max Panel Thickness
Head Diameter
Length
The size chart you provided appears to be for a range of locking nylon fasteners or plugs, typically used in various industrial or commercial applications. Here’s a breakdown of the key specifications for these parts:
Code | To Fit Hole Diameter | Max Panel Thickness | Head Diameter | Length | Colour | Locking Position | Material |
---|---|---|---|---|---|---|---|
MK070 | 34.2mm | 4.1mm | 38.1mm | 11.5mm | Black | Multiple | Nylon |
MK071 | 34.2mm | 4.1mm | 38.1mm | 11.5mm | White | Multiple | Nylon |
MK072 | 34.9mm | 6.4mm | 38.1mm | 14.3mm | Black | Multiple | Nylon |
MK073 | 34.9mm | 6.4mm | 38.1mm | 14.3mm | White | Multiple | Nylon |
MK074 | 34.9mm | 3.2mm | 38.1mm | 11.5mm | White | Multiple | Nylon |
MK075 | 34.9mm | 3.2mm | 38.1mm | 11.5mm | Black | Multiple | Nylon |
MK076 | 34.9mm | 3.2mm | 38.1mm | 14.3mm | Black | Multiple | Nylon |
MK077 | 38.1mm | 3.2mm | 42.4mm | 11.5mm | White | Multiple | Nylon |
MK078 | 38.1mm | 3.2mm | 42.4mm | 11.5mm | Black | Multiple | Nylon |
MK079 | 38.1mm | 3.2mm | 42.1mm | 11.2mm | Black | Multiple | Nylon |
MK080 | 38.1mm | 6.4mm | 42.4mm | 14.3mm | Black | Multiple | Nylon |
MK081 | 38.1mm | 6.4mm | 42.4mm | 14.3mm | White | Multiple | Nylon |
MK082 | 41.3mm | 3.2mm | 45.7mm | 11.5mm | Black | Multiple | Nylon |
MK083 | 41.3mm | 3.2mm | 45.7mm | 11.5mm | White | Multiple | Nylon |
MK084 | 44.5mm | 6.4mm | 48.4mm | 14.3mm | Black | Multiple | Nylon |
MK085 | 44.5mm | 6.4mm | 48.4mm | 14.3mm | White | Multiple | Nylon |
MK086 | 44.5mm | 3.2mm | 48.7mm | 11.5mm | White | Multiple | Nylon |
MK087 | 44.5mm | 3.2mm | 48.7mm | 11.5mm | Black | Multiple | Nylon |
MK088 | 44.5mm | 3.2mm | 49.7mm | 11.8mm | Black | Multiple | Nylon |
MK089 | 47.6mm | 3.2mm | 52.1mm | 11.9mm | Black | Multiple | Nylon |
MK090 | 47.6mm | 3.2mm | 52.1mm | 11.9mm | White | Multiple | Nylon |
MK091 | 50.8mm | 6.4mm | 55.1mm | 14.7mm | Black | Multiple | Nylon |
MK092 | 50.8mm | 6.4mm | 55.1mm | 14.7mm | White | Multiple | Nylon |
MK093 | 50.8mm | 3.2mm | 55.1mm | 11.9mm | Black | Multiple | Nylon |
MK094 | 50.8mm | 3.2mm | 55.1mm | 11.9mm | White | Multiple | Nylon |
MK095 | 51mm | 3.2mm | 55mm | 11.5mm | Black | None | Nylon |
MK096 | 51mm | 3.2mm | 55mm | 11.5mm | White | None | Nylon |
MK097 | 53.2mm-54mm | 6.4mm | 59.9mm | 19.1mm | Black | Multiple | Nylon |
MK098 | 53.2mm-54mm | 6.4mm | 59.9mm | 19.1mm | White | Multiple | Nylon |
MK099 | 57.2mm | 6.4mm | 63mm | 19.1mm | Black | Multiple | Nylon |
MK100 | 57.2mm | 6.4mm | 63mm | 19.1mm | White | Multiple | Nylon |
MK101 | 63.5mm | 6.4mm | 68.8mm | 19.1mm | Black | Multiple | Nylon |
MK102 | 63.5mm | 6.4mm | 68.8mm | 19.1mm | White | Multiple | Nylon |
MK103 | 76.2mm | 6.4mm | 80.5mm | 18.2mm | Black | Multiple | Nylon |
MK104 | 76.2mm | 6.4mm | 80.5mm | 18.2mm | White | Multiple | Nylon |
MK105 | 85.7mm | 6.4mm | 92.8mm | 19.1mm | Black | Multiple | Nylon |
MK106 | 85.7mm | 6.4mm | 92.8mm | 19.1mm | White | Multiple | Nylon |
MK107 | 88.9mm | 6.4mm | 92.9mm | 19.1mm | Black | Multiple | Nylon |
MK108 | 88.9mm | 6.4mm | 92.9mm | 19.1mm | White | Multiple | Nylon |
MK109 | 101.6mm | 6.4mm | 105.8mm | 18mm | Black | Multiple | Nylon |
MK110 | 101.6mm | 6.4mm | 105.8mm | 18mm | White | Multiple | Nylon |
MK111 | 127mm | 6.4mm | 133mm | 19.1mm | Black | Multiple | Nylon |
MK112 | 127mm | 6.4mm | 133mm | 19.1mm | White | Multiple | Nylon |
MK113 | 152.4mm | 6.4mm | 157.9mm | 19.8mm | Black | Multiple | Nylon |
MK114 | 152.4mm | 6.4mm | 157.9mm | 19.8mm | White | Multiple | Nylon |
Conclusion
Professional Blanking Plugs are an essential component for any industrial setup requiring reliable and aesthetically pleasing hole seals. Their robust construction, ease of use, and versatile design make them a valuable addition to any panel assembly. Whether you need to blank off excess holes or create clean cable threading ports, these plugs deliver superior performance and durability.
