Product Overview

This Premium Heavy Duty ratchet strap is engineered for restraining very large industrial plant and machinery. With a robust design and impressive specifications, it’s perfect for heavy lifting and securing loads.

Key Features

• 75mm wide webbing for enhanced strength and durability.
• Powerful ratchet tensioner equipped with a double lock handle for added security.
• Lashing capacity of 5000 daN (Kg) ensuring reliable load management.
• Minimum breaking force of 10,000 daN (Kg) when new.
• Ratchets operate with a force of 50 DaN Standard Hand Force (SHF) and 350 DaN Standard Tension Force (STF).
• 300mm length 3-ply tail strap standard for versatile application.
• Low elongation webbing, less than 7% at working load limit (LC), for stable load securing.
• Overall length of 10 metres, ideal for large loads.
• Available in an endless (continuous loop) format for comprehensive use.
• Additional sizes can be manufactured to order based on specific requirements.

Dimensions & Specifications

Technical Specifications

• Material: High-performance webbing
• Application: Industrial use for securing heavy machinery
• Usage: Ideal for transportation and storage of large equipment

FAQ

• Q: What is the maximum load this ratchet strap can handle?
  A: The ratchet strap has a minimum breaking force of 10,000 daN (Kg).
• Q: Can I order different sizes?
  A: Yes, other sizes can be manufactured to order.
• Q: What is the width of the webbing?
  A: The webbing is 75mm wide.
