Wheel Specifications

Mounting Plate Details

Castor Dimensions

Load Capacity

Industrial Trolleys

Material handling carts, platform trolleys, and warehouse transport equipment requiring directional stability

Food Service Equipment

Catering trolleys, service carts, and kitchen equipment in commercial food preparation environments

Healthcare Facilities

Medical carts, patient transport equipment, and hospital trolleys requiring hygienic, non-marking wheels

Warehouse Operations

Stock picking carts, order fulfilment trolleys, and logistics equipment in distribution centres

What is the difference between fixed and swivel castors?

Fixed castors only move in a straight line along their mounted axis, providing directional stability and controlled tracking. Swivel castors rotate 360 degrees, allowing multi-directional movement. Most equipment uses a combination of both types for optimal manoeuvrability and control.

Can these castors be used on uneven surfaces?

These castors are designed for smooth, flat surfaces such as concrete floors, tiles, and sealed surfaces. While they can traverse minor surface irregularities, they perform best on level ground. For rough or uneven terrain, larger diameter wheels or pneumatic castors may be more suitable.

What does the 120kg load capacity mean?

The 120kg rating indicates the maximum safe load per individual castor. When using four castors on a trolley, the total capacity would be 480kg. Always distribute weight evenly across all castors and include a safety margin. Never exceed the stated capacity to ensure safe operation and longevity.

Are white nylon wheels suitable for food environments?

Yes, white nylon wheels are specifically chosen for hygienic environments including food processing, commercial kitchens, and pharmaceutical facilities. The non-marking material prevents floor contamination, is easy to clean, and resists moisture. The white colour also makes contamination visible for easier inspection.

How do I determine the correct castor size for my application?

Consider three factors: load capacity, floor surface, and manoeuvrability requirements. Larger wheels roll more easily over obstacles and uneven surfaces. Calculate total equipment weight including maximum load, divide by number of castors, and add a 25-30% safety margin. This 80mm castor suits medium-duty applications on smooth floors.

Will these castors mark or damage my floors?

White nylon wheels are specifically designed to be non-marking and floor-friendly. They will not leave black scuff marks like rubber wheels and are gentle on polished surfaces, tiles, and sealed concrete. Regular cleaning of the wheels helps maintain this non-marking property.

What maintenance do these castors require?

Minimal maintenance is required. Periodically inspect for debris wrapped around the wheel axle, check mounting bolts remain tight, and verify the wheel rotates freely. Clean wheels regularly in hygienic environments. The ball journal bearing is designed for long-term performance with minimal intervention.

Can I mix fixed and swivel castors on the same equipment?

Yes, this is the recommended configuration for most trolleys and carts. Typically, fixed castors are mounted at one end for directional stability, while swivel castors at the opposite end allow steering and turning. This combination provides both manoeuvrability and controlled movement.
