Product Overview
This premium all-in-one video processing controller is designed for high-performance video applications, offering exceptional pixel capacity and versatile connectivity options. With a loading capacity of up to 13 million pixels, it is ideal for professional video setups.
Features
- High loading capacity up to 13 million pixels
- Multiple input connectors including 12G-SDI, HDMI, and USB
- Robust output options with Ethernet ports and HDMI loops
- Control via Ethernet and USB for seamless integration
- Multiple preset configurations for quick setup
Dimensions & Specifications
| Device Model | Loading Capacity | Max Width (pixels) | Max Height (pixels) | Layers |
|---|---|---|---|---|
| VX2000 Pro | 13 million pixels | 16384 | 8192 | 12×2K |
| VX1000 | 6.5 million pixels | 10240 | 8192 | 1×MAIN+2×PIP |
| VX600 | 3.9 million pixels | 10240 | 8192 | 1×MAIN+2×PIP |
| VX400 | 2.6 million pixels | 10240 | 8192 | 1×MAIN+1×PIP |
Input and Output Connectors
- Input Connectors:
- 1×12G-SDI
- 1×DP 1.2
- 2×HDMI 2.0
- 4×HDMI 1.3
- 2×OPT
- 1×USB3.0
- Output Connectors:
- 20×Ethernet Ports
- 1×HDMI1.3
- 4×OPT
- 1×12G-SDI LOOP
Control Connectors
- 2×Ethernet Port
- 1×USB
FAQ
What is the maximum pixel capacity of this controller?
The maximum pixel capacity is 13 million pixels.
What types of input connectors are available?
The controller features a variety of input connectors including SDI, HDMI, and USB.
Can this controller handle multiple layers?
Yes, the VX2000 Pro can manage up to 12 layers of 2K video.
Premium All-in-One Video Processing Controller with High Pixel Capacity and Versatile Connectivity Options
Dispatch
Checkout
Guaranteed
Returns
Download Spec Sheet
PDF with image, specifications & dimensions
| SKU | 15279690940801 |
| Brand | Industrial Products UK |
| Product Type | Industrial Hardware > Castors & Wheels |
| Title | Default Title |
| Barcode | IPU-ROLL-STD-56C5 |
- Premium All-in-One Video Processing Controller with High Pixel Capacity and Versatile Connectivity Options
- VAT invoice for business accounting
- Product documentation (where applicable)
Description
Product Overview
This premium all-in-one video processing controller is designed for high-performance video applications, offering exceptional pixel capacity and versatile connectivity options. With a loading capacity of up to 13 million pixels, it is ideal for professional video setups.
Features
- High loading capacity up to 13 million pixels
- Multiple input connectors including 12G-SDI, HDMI, and USB
- Robust output options with Ethernet ports and HDMI loops
- Control via Ethernet and USB for seamless integration
- Multiple preset configurations for quick setup
Dimensions & Specifications
| Device Model | Loading Capacity | Max Width (pixels) | Max Height (pixels) | Layers |
|---|---|---|---|---|
| VX2000 Pro | 13 million pixels | 16384 | 8192 | 12×2K |
| VX1000 | 6.5 million pixels | 10240 | 8192 | 1×MAIN+2×PIP |
| VX600 | 3.9 million pixels | 10240 | 8192 | 1×MAIN+2×PIP |
| VX400 | 2.6 million pixels | 10240 | 8192 | 1×MAIN+1×PIP |
Input and Output Connectors
- Input Connectors:
- 1×12G-SDI
- 1×DP 1.2
- 2×HDMI 2.0
- 4×HDMI 1.3
- 2×OPT
- 1×USB3.0
- Output Connectors:
- 20×Ethernet Ports
- 1×HDMI1.3
- 4×OPT
- 1×12G-SDI LOOP
Control Connectors
- 2×Ethernet Port
- 1×USB
FAQ
What is the maximum pixel capacity of this controller?
The maximum pixel capacity is 13 million pixels.
What types of input connectors are available?
The controller features a variety of input connectors including SDI, HDMI, and USB.
Can this controller handle multiple layers?
Yes, the VX2000 Pro can manage up to 12 layers of 2K video.
