Description
75mm · 10,000daN · Ergo · Ratchet Lashing System · Claw Hooks
Extreme duty lashings for Heavy Plant Transport, Rail, Marine Cargo and Industrial applications
Please note this a heavy duty lashing both in scale and physical weight, it's NOT suitable as an alternative to 50mm wide ratchet lashings for general road haulage.
- 2-Part System, comprising ratchet with fixed end plus main tension (adjustable) strap, both terminating in claw hooks
- Breaking Force Minimum (BFmin) 10,000daN (kg)- Lashing Capacity (LC) 5000daN (kg)
- 15,000daN (kg) BFmin heavy duty polyester webbing, elongation (stretch) < 7% @ LC
- Standard Tension Force (STF) 500daN (kg) - using a Standard Hand Force (SHF) of 50daN (kg)
- 0.3m fixed end (tail), fitted with a Ergonomic Ratchet
- 6.0m overall length
- Manufactured and labelled in accordance with BS EN 12195-2:2001
Powerful ratchet tensioner with double lock handle.
Ergonomic action tensions strap by pulling the handle down providing more Standard Tension Force.
Wear sleeves or corner protectors are recommended at all times to protect the webbing straps.
10,000kg ERGO Ratchet Strap with Claw Hooks - 6 Metres
Dispatch
Checkout
Guaranteed
Returns
Download Spec Sheet
PDF with image, specifications & dimensions
| SKU | IP_NTP4906 |
| Brand | Industrial Products UK |
| Product Type | Cargo Control > Ratchet Straps |
| Title | Default Title |
| Barcode | IPU-RATCHET-000KG-6M-2688-1 |
- 10,000kg ERGO Ratchet Strap with Claw Hooks - 6 Metres
- VAT invoice for business accounting
- Product documentation (where applicable)
Description
75mm · 10,000daN · Ergo · Ratchet Lashing System · Claw Hooks
Extreme duty lashings for Heavy Plant Transport, Rail, Marine Cargo and Industrial applications
Please note this a heavy duty lashing both in scale and physical weight, it's NOT suitable as an alternative to 50mm wide ratchet lashings for general road haulage.
- 2-Part System, comprising ratchet with fixed end plus main tension (adjustable) strap, both terminating in claw hooks
- Breaking Force Minimum (BFmin) 10,000daN (kg)- Lashing Capacity (LC) 5000daN (kg)
- 15,000daN (kg) BFmin heavy duty polyester webbing, elongation (stretch) < 7% @ LC
- Standard Tension Force (STF) 500daN (kg) - using a Standard Hand Force (SHF) of 50daN (kg)
- 0.3m fixed end (tail), fitted with a Ergonomic Ratchet
- 6.0m overall length
- Manufactured and labelled in accordance with BS EN 12195-2:2001
Powerful ratchet tensioner with double lock handle.
Ergonomic action tensions strap by pulling the handle down providing more Standard Tension Force.
Wear sleeves or corner protectors are recommended at all times to protect the webbing straps.
