Description
Premium High-Performance Turf Nozzles
These premium turf nozzles are engineered for optimal spray application, enhancing the effectiveness of treatments with less drift. The larger droplets produced significantly reduce the risk of drift, allowing for more precise and timely applications. Research indicates that the 04 XC foliar nozzle generates less than 3% of small droplets susceptible to drift, compared to 14% from traditional flat fan nozzles. This innovation leads to an average of three to four additional days each month suitable for spraying, ensuring improved results.
Application Efficiency
- Forward speed impacts the volume of water applied, with a reduction in speed increasing the application rate by 50%.
- Higher operating pressure increases water volume but may heighten drift risk. Conversely, reducing pressure lowers drift but can affect spray pattern and droplet momentum.
- Most nozzles function best at three to four bar pressure.
By selecting different nozzle sizes, you can optimize the application for various turf situations. For consistent application at two to three bar, consider the following:
- 025 nozzles for greens deliver 200 - 300 l/ha at four to five km/h.
- 04 nozzles apply 220 - 380 l/ha at five to seven km/h for fairways.
- 08 nozzles provide 450 - 770 l/ha at five to seven km/h.
Nozzle Output
| Speed | 4 km/h | 4 km/h | 7 km/h | 7 km/h |
|---|---|---|---|---|
| Pressure Bar (Colour) | 2 | 3 | 2 | 3 |
| 025 (Purple) | 245 | 300 | 140 | 171 |
| 04 (Red) | 392 | 480 | 224 | 274 |
| 08 (White) | 784 | 960 | 448 | 590 |
This table illustrates the nozzle output (l/ha) for the premium turf XC nozzles at typical spraying speeds and pressures.
Technical Specifications
- Nozzle Sizes Available: 025, 04, 08
- Operating Pressure: 2-3 Bar recommended
- Application Rate: Varies by nozzle size and speed
Frequently Asked Questions (FAQ)
Q: How do I select the right nozzle size?
A: Choose based on the specific application needs and desired water volume.
Q: What is the optimal operating pressure for these nozzles?
A: The nozzles work most efficiently at three to four bar pressure.
Q: Can I achieve different output rates with the same nozzle?
A: Yes, by adjusting speed and pressure, you can vary the water volume applied.
Premium High-Performance Turf Nozzles - Precision Application with Reduced Drift for Effective Spraying
Dispatch
Checkout
Guaranteed
Returns
Download Spec Sheet
PDF with image, specifications & dimensions
| SKU | 17249 |
| Brand | Syngenta |
| Product Type | Safety & Access > Equipment > Spraying Equipment > Spray Nozzles & Accessories |
| Colour | White |
- Premium High-Performance Turf Nozzles - Precision Application with Reduced Drift for Effective Spraying
- VAT invoice for business accounting
- Product documentation (where applicable)
Description
Premium High-Performance Turf Nozzles
These premium turf nozzles are engineered for optimal spray application, enhancing the effectiveness of treatments with less drift. The larger droplets produced significantly reduce the risk of drift, allowing for more precise and timely applications. Research indicates that the 04 XC foliar nozzle generates less than 3% of small droplets susceptible to drift, compared to 14% from traditional flat fan nozzles. This innovation leads to an average of three to four additional days each month suitable for spraying, ensuring improved results.
Application Efficiency
- Forward speed impacts the volume of water applied, with a reduction in speed increasing the application rate by 50%.
- Higher operating pressure increases water volume but may heighten drift risk. Conversely, reducing pressure lowers drift but can affect spray pattern and droplet momentum.
- Most nozzles function best at three to four bar pressure.
By selecting different nozzle sizes, you can optimize the application for various turf situations. For consistent application at two to three bar, consider the following:
- 025 nozzles for greens deliver 200 - 300 l/ha at four to five km/h.
- 04 nozzles apply 220 - 380 l/ha at five to seven km/h for fairways.
- 08 nozzles provide 450 - 770 l/ha at five to seven km/h.
Nozzle Output
| Speed | 4 km/h | 4 km/h | 7 km/h | 7 km/h |
|---|---|---|---|---|
| Pressure Bar (Colour) | 2 | 3 | 2 | 3 |
| 025 (Purple) | 245 | 300 | 140 | 171 |
| 04 (Red) | 392 | 480 | 224 | 274 |
| 08 (White) | 784 | 960 | 448 | 590 |
This table illustrates the nozzle output (l/ha) for the premium turf XC nozzles at typical spraying speeds and pressures.
Technical Specifications
- Nozzle Sizes Available: 025, 04, 08
- Operating Pressure: 2-3 Bar recommended
- Application Rate: Varies by nozzle size and speed
Frequently Asked Questions (FAQ)
Q: How do I select the right nozzle size?
A: Choose based on the specific application needs and desired water volume.
Q: What is the optimal operating pressure for these nozzles?
A: The nozzles work most efficiently at three to four bar pressure.
Q: Can I achieve different output rates with the same nozzle?
A: Yes, by adjusting speed and pressure, you can vary the water volume applied.
