Premium Travelling Sprinkler
This travelling sprinkler offers a cost-effective and easy-to-operate turf irrigation solution, ideal for lawns, cricket pitches, bowling greens, and other areas requiring precise automated watering with an automatic stop function.
Designed for light to medium levels of use, this sprinkler provides controlled irrigation with three speed settings: High (HI), Low (LO), and Neutral (N). This allows you to apply light watering, heavy watering, or, when in neutral, use it as a static sprinkler for a slow soak in a particular area.
Features
- Custom self-propelled watering pattern determined by the layout of the hose pipe.
- A shut-off ramp is included to automatically stop the sprinkler.
- Coverage diameter ranges from 5 to 14 metres, adjustable by twisting the spray arms.
- Constructed from rust-proof cast iron with chip-resistant paint.
- Travels up to 61 metres.
- Can cover up to 1000m2.
- Adjustable aluminium spray arms provide coverage widths from 4.5m to 16.5m, depending on water pressure and hose diameter.
- Features a two-speed transmission with an automatic shut-off device.
- Includes a neutral gear for static watering.
- Operates with water pressures of 2.8 bar (40 psi) and above.
- Comes with full instructions for setup and operation.
Setting up your Premium Travelling Sprinkler
To set up, connect your hose pipe to a tap and lay it out in the middle of the intended irrigation area, using wide gradual turns wherever possible. Route the hose pipe around obstacles to ensure all areas are covered.
Position the front wheel of the sprinkler at the end of the hose run, with the sprinkler facing back towards the tap. Loop the end of the hose back on itself and connect it to the sprinkler. Once a gear is selected and the water is turned on, the sprinkler will follow the hose pipe back towards the tap.
Stopping Your Premium Travelling Sprinkler
This sprinkler is designed to automatically shut off at any point along your hose track using the supplied ramp. The ramp applies pressure to a shut-off switch located beneath the sprinkler as it travels over it.
Please Note: Some light dripping may occur from the shut-off switch during operation; this is normal and does not indicate a fault.
Technical Specifications
| Specification | Measurement |
|---|---|
| Diameter of Coverage | 5 to 14 metres |
| Travel Distance | Up to 61 metres |
| Coverage Area | Up to 1000m2 |
| Spray Arms Adjustment | 4.5m to 16.5m |
| Water Pressure | 2.8 bar (40 psi) and above |
Frequently Asked Questions
- How do I set up the sprinkler? Simply connect the hose to a tap, lay it in the desired pattern, and connect to the sprinkler.
- Can I use it on uneven terrain? Yes, the sprinkler can navigate around obstacles as long as the hose is laid out properly.
- What should I do if it doesn’t shut off? Ensure the ramp is properly positioned and that the sprinkler is functioning correctly.
